CE/GS approval Safe working load: 1Ton Standard lift: 3m Load chain fall: 1 Dynamic load: 15KN Chain pull to lift full load: 250N Load chain diameter: 6x18mm Sealed roller bearing Packing: color box

Stock No.	Safe working load	Standard lift	Load chain fall	Dynamic load	Chain pull to lift full load	Load chain diameter	Qty./ carton
62401	1 Ton	3m	1	15KN	250N	6x18mm	1

CE/GS approval Safe working load: 2Ton Standard lift: 3m Load chain fall: 1 Dynamic load: 30KN Chain pull to lift full load: 335N Load chain diameter: 8x24mm Sealed roller bearing Packing: color box

Stock No.	Safe working load	Standard lift	Load chain fall	Dynamic load	Chain pull to lift full load	Load chain diameter	Qty./ carton
62402	2 Ton	3m	1	30KN	335N	8x24mm	1

CE approval Input power: 800W Rated Voltage: 230V Frequency:50Hz Lifting weight:250Kgs(Single line) 500Kgs(Double line) Lifting height:12m(Single line),6m(Double line) Lifting speed:8m/min(Single line),4m/min(Double line) Upper and lower limit device Emergency stop switch Thermal protection terminal Packing: color box

STOCK NO.	LIFTING WEIGHT	QTY./CARTON
62491	250kg/500kg	2

CE approval Input power: 1600W Rated Voltage: 230V Frequency:50Hz Lifting weight:500Kgs(Single line) 999Kgs(Double line) Lifting height:12m(Single line),6m(Double line) Lifting speed:8m/min(Single line),4m/min(Double line) Upper and lower limit device Emergency stop switch Thermal protection terminal Packing: color box

STOCK NO.	LIFTING WEIGHT	QTY./CARTON
62492	500kg/999kg	1

• CE approved • 2 times longer life • Leak-proof welded construction • Steel plate instead of cast iron for environment protection • Preventing oil leakage • Oil remaining clear after using • Packing: color box

STOCK NO.	CAPACITY	MIN. HEIGHT	LIFT HEIGHT	ADJUSTABLE HEIGHT	NET WEIGHT	QTY./CARTON
65390	2 Tons	168 mm	100 mm	48 mm	1.9kgs	6
65392	4 Tons	188 mm	115mm	60mm	2.6kgs	6
65393	6 Tons	207mm	125mm	70mm	3.31kgs	4
65395	10 Tons	222mm	145mm	80mm	4.35kgs	4
65397	20 Tons	235mm	150mm	60mm	8.2kgs	2
65398	32 Tons	278mm	165mm		12.75kgs	1
65399	50 Tons	265mm	160mm		25kgs	1

• CE approval • Slow descending with load • Steel plate instead of cast iron for environment protection • Preventing from oil leakage • Oil remaning clear after using • Packed by color box

STOCK NO.	CAPACITY	MIN HEIGHT	LIFT HEIGHT	ADJUSTABLE HEIGHT	NET WEIGHT	QTY./CARTON
65402	2Tons	175mm	116mm	48mm	2.38kgs	6
65404	4Tons	190mm	118mm	60mm	2.5kgs	6
65406	6Tons	210mm	127mm	70mm	4.02kgs	4
65410	10Tons	225mm	145mm	80mm	5.4kgs	4
65420	20Tons	240mm	150mm	60mm	10.06kgs	2
65421	32 Tons	260mm	160mm		17.8kgs	1
65422	50 Tons	280mm	170mm		25.8kgs	1
