CE/GS approval Safe working load: 2Ton Standard lift: 3m Load chain fall: 1 Dynamic load: 30KN Chain pull to lift full load: 335N Load chain diameter: 8x24mm Sealed roller bearing Packing: color box

Stock No.	Safe working load	Standard lift	Load chain fall	Dynamic load	Chain pull to lift full load	Load chain diameter	Qty./ carton
62402	2 Ton	3m	1	30KN	335N	8x24mm	1

CE/GS approval Safe working load: 3Ton Standard lift: 3m Load chain fall: 2 Dynamic load: 45KN Chain pull to lift full load: 265N Load chain diameter: 7.1x21mm Sealed roller bearing Packing: color box

Stock No.	Safe working load	Standard lift	Load chain fall	Dynamic load	Chain pull to lift full load	Load chain diameter	Qty./ carton
62403	3 Ton	3m	2	45KN	265N	7.1x21mm	1

CE approval Input power: 1600W Rated Voltage: 230V Frequency:50Hz Lifting weight:500Kgs(Single line) 999Kgs(Double line) Lifting height:12m(Single line),6m(Double line) Lifting speed:8m/min(Single line),4m/min(Double line) Upper and lower limit device Emergency stop switch Thermal protection terminal Packing: color box

STOCK NO.	LIFTING WEIGHT	QTY./CARTON
62492	500kg/999kg	1

• S.F.: 7:1 • The idea of lifting and moving heavy things • Made from high tenacity 100% polyester webbing with reinforced eye loops at both ends. • High durability of scratch, friction, wear and tear • More flexible and lighter, resistant to cutting and abrasion • Packing: color label with shrink

STOCK NO.	SIZE	COLOR	QTY./CARTON
62266	1Tx1M	Violet	64
62267	1Tx2M	Violet	32
62268	1Tx3M	Violet	24
62269	2Tx1M	Green	32
62270	2Tx2M	Green	16
62271	2Tx3M	Green	12
62272	2Tx4M	Green	20
62273	2Tx5M	Green	18
62274	2Tx6M	Green	15
62275	3Tx2M	Yellow	20
62276	3Tx3M	Yellow	15
62277	3Tx4M	Yellow	12
62278	3Tx5M	Yellow	12
62279	3Tx6M	Yellow	9
62280	4Tx3M	Grey	10
62281	4Tx4M	Grey	8
62282	4Tx5M	Grey	8
62283	4Tx6M	Grey	6
62284	5Tx3M	Red	10
62285	5Tx4M	Red	8
62286	5Tx5M	Red	6
62287	5Tx6M	Red	6
62288	5Tx8M	Red	4
62289	6Tx4M	Brown	5
62290	6Tx5M	Brown	5
62291	6Tx6M	Brown	4
62292	6Tx8M	Brown	3
62295	8Tx6M	Blue	3
62296	8Tx8M	Blue	2
62298	10Tx6M	Orange	2
62299	10Tx8M	Orange	2
62300	10Tx10M	Orange	1



• CE approval • Slow descending with load • Steel plate instead of cast iron for environment protection • Preventing from oil leakage • Oil remaning clear after using • Packed by color box

STOCK NO.	CAPACITY	MIN HEIGHT	LIFT HEIGHT	ADJUSTABLE HEIGHT	NET WEIGHT	QTY./CARTON
65402	2Tons	175mm	116mm	48mm	2.38kgs	6
65404	4Tons	190mm	118mm	60mm	2.5kgs	6
65406	6Tons	210mm	127mm	70mm	4.02kgs	4
65410	10Tons	225mm	145mm	80mm	5.4kgs	4
65420	20Tons	240mm	150mm	60mm	10.06kgs	2
65421	32 Tons	260mm	160mm		17.8kgs	1
65422	50 Tons	280mm	170mm		25.8kgs	1



• CE approval • Heavy duty • Fast lifting dual pump • Packing: color box

STOCK NO.	CAPACITY	MIN HEIGHT	MAX HEIGHT	NET WEIGHT	QTY./CARTON
65464	3Tons	130mm	465mm	29.3kgs	1
