AUTOMATIC AIR LINE HOSE REEL (INDUSTRIAL)
• CE approval
• Oversize: 53x49x23cm
• Keep work space free from unwanted lengths of hose
• Working pressure: 10bar / 150psi
• Supplied with 15m+1.5m of PVC air line hose size
3/8"(9.5x15.8mm)
• Hose connection 1/4" BSPT male thread
• Max working pressure of hose: 300psi
• Packing: color box
| STOCK NO. | SIZE | QTY./ CATRON |
| 73159 | 15M/50ft | 1 |
1/2“ AIR IMPACT WRENCH
• CE approved
• Square drive: 1/2"
• Twin hammer provides more torque and less vibration
• Operating air pressure: 6.2BAR (90PSI)
• Average air consumption: 120L/min (with 5-speed
regulator)
• Air inlet: 1/4"
• Air hose: 3/8"
• Max. torque: 1000NM (735FT-LB )
• Free speed: 6000 rpm
• Net weight: 2.76KGS
• Packing: color box
| STOCK NO. | SQUARE DRIVE | QTY./CARTON |
| 73302 | 1/2" | 6 |
1/2″ AIR IMPACT WRENCH (INDUSTRIAL)
• CE approved
• Square drive: 1/2"
• Twin hammer provides more torque and less vibration
• Operating air pressure: 6.2BAR (90PSI)
• Average air consumption: 120L/min (with 5-speed regulartor)
• Air inlet : 1/4“
• Air hose: 3/8"
• Max torque: 640NM (470FT-LB )
• Free speed: 7500 rpm
• Net weight: 2.76KGS
• Packing: color box
| STOCK NO. | SQUARE DRIVE | QTY./ CATRON |
| 73301 | 1/2" | 6 |
1300N.m 1/2″ AIR IMPACT WRENCH (INDUSTRIAL)
CE approval
Twin hammer
Square drive: 1/2"
Max Torque: 1300N.m / 958Ft-lb
• Free speed: 7000rpm
• Working pressure: 6.2bar (80psi)
• Air consumption: 128L/min (with 3-speed regulator)
• Air hose: 3/8"
• Air inlet: 1/4" (G type)
• Net weight: 2.2kg
• Packing: color box
| STOCK NO. | SQUARE DRIVE | QTY./CARTON |
| 73363 | 1/2" | 6 |
17PCS AIR IMPACT WRENCH SET
• CE approval
• 1pc 1/2" Air Impact Wrench:
Operating air pressure: 6.2BAR (90PSI)
Average air consumption: 210L/min
Air inlet size: 3/8"
Max torque: 340NM (250FT-LB )
Free speed: 7000 rpm
Net weight: 2.18KGS
• 10pcs impact sockets 9, 10, 11, 13, 14, 17, 19, 22, 24,
27mm
• 1pc extension bar: 1/2"x 5"
• 1pc 4mm hex wrench
• 1pc oil can
• 1pc nipple
• 1pc grease injector
• Packing: blow mould case with color sleeve
| STOCK NO. | SIZE | QTY./ CATRON |
| 73382 | 1/2" | 4 |
9PCS AIR HAMMER SET (HEX)
• CE approval
• 1pc Air hammer :
Operating air pressure: 6.2BAR (90PSI)
Operating length: 41mm
Average air consumption: 140L/min
Air inlet size: 3/8"
Impact rate: 4500 bpm
Net weight: 1.13KGS
• 4pcs Hex shank chisels 125mm
• 1pc oil can
• 1pc nipple
• 1pc spring retainer
• Packing: blow mould case with color sleeve
| STOCK NO. | QTY./ CATRON |
| 73384 | 6 |
2 IN 1 BRAD NAILER (INDUSTRIAL)
• CE approval
• Suitable for brads:
F brads 18Ga. 1.26x1.05mm: 10-50mm
K brads 18Ga. 1.26x1.05mm: 13-40mm
• Magazine capacity: 100pcs
• Operating pressure: 70psi(0.5Mpa)-110psi(0.75Mpa)
• Air inlet: 1/4"
• Net weight: 1.3kg
• 360° adjustable exhaust
• Depth adjustable
• No-mar tip protects work surface
• Reload indicator
• Accessories：
300pcs F brads
300pcs K brads
2pcs hex key
1pc oil pot
3pcs quick coupler with 1/4" PT male thread
• Packing: color box
| STOCK NO. | QTY./CARTON |
| 73420 | 6 |
AIR STAPLER (INDUSTRIAL)
• CE approval
• Suitable for staples:
Crown staples 21Ga. 0.95*0.66mm: 6-16mm
• Magazine capacity: 120pcs
• Operating pressure: 60psi(0.4Mpa)-100psi(0.7Mpa)
• Air inlet: 1/4"
• Net weight: 0.8kg
• Ideal for upholstering, cabinet assembly, furniture
manufacturing
• Accessories:
300pcs Crown staples
2pcs hex key
1pc oil pot
3pcs quick coupler with 1/4" PT male thread
• Packing: color box
| STOCK NO. | QTY./CARTON |
| 73425 | 8 |
3HP 200L AIR COMPRESSOR (INDUSTRIAL)
• Copper wire induction motor
• Input power: 2200W / 3Hp
• Rated Voltage: 220-240V
• Frequency:50Hz
• Tank: 200L
• Air displacement: 370L/min
• Max pump pressure: 8Bar(116psi)
• Noise:83db
• Belt driving system
• Pump lubricated with oil
• Packing: wood box
| STOCK NO. | SIZE | TANK | QTY./CARTON |
| 73118 | 3Hp (2200W) | 200L | 1 |
5.5HP 300L AIR COMPRESSOR (INDUSTRIAL)
• Copper wire induction motor
• Input power: 4100W / 5.5Hp
• Rated Voltage: 380V
• Frequency:50Hz
• Tank: 300L
• Air displacement: 600L/min
• Max pump pressure: 8Bar(116psi)
• Noise:83db
• Belt driving system
• Pump lubricated with oil
• Packing: wood box
| STOCK NO. | SIZE | TANK | QTY./CARTON |
| 73119 | 5.5Hp (4100W) | 300L | 1 |
3HP 100L AIR COMPRESSOR
• Input power: 2200W / 3Hp
• Rated Voltage: 230V
• Frequency:50HZ
• Air displacement: 250L/min
• Max pump pressure: 8Bar(116psi)
• Noise:92db
• Belt driving system
• Pump lubricated with oil
• Features:
• Suitable for workshop use
• Thermal motor protection overload
• Pressure regulator and pressure gauge
• Wheels and transport
| STOCK NO. | SIZE | TANK | QTY./CARTON |
| 73130 | 3Hp (2200W) | 100L | 1 |
