13PCS VDE INSULATED SCREWDRIVER SET
• VDE/GS certificated
• 4pcs Slotted: 1.2x6.5x100mm,1x5.5x100mm,0.8x4x100mm,0.5x3x100mm
• 2pcs Phillips: PH2x100mm,PH1x80mm
• 2pcs Pozidriv: PZ2x100mm, PZ1x80mm
• 3pcs Torx: T20x100mm,T15x100mm,T10x100mm
• 1Pc single-pole voltage tester
• 1Pc screwdriver handle
• Packing: color box
| STOCK NO. | QTY./CARTON |
| 38016 | 12 |
ADJUSTABLE AUTOMATIC WIRE STRIPPER
• 2-IN-1 Wire stripper & cutter
• Applicable wire stripper size: 0.5mm² - 6mm²
• Self-adjustable mechanism according to wire size provides excellent wire stripping
• Adjustable stop for consistency in wire strip lengths, replaceable blade system
• Strip 8mm width flat cable also applicable
• Simple adjustment dial for blade pressure according to the thickness of insulation
• Packing: blister card
| STOCK NO. | SIZE | QTY./CARTON |
| 38050 | 0.5-6mm² | 48 |
WIRE CUTTER AND WIRE STRIPPER (INDUSTRIAL)
• Made of CrV steel
• Lightweight wire stripper and cutter cleanly cut solid and standard copper wire.
• Comfortable grip handle helps to provide high leverage.
• Coil spring provides fast self-opening action.
• Strips and cuts 16-8 AWG
• Packing: blister card
| STOCK NO. | SIZE | QTY./CARTON |
| 38053 | 190mm, 7.5" | 72 |
RATCHET MODULAR CRIMPING PLIERS
• Carbon steel with hardened and tempered frame
• Chemically black finished surface
• PP/TPR Two-component grips
• Compact and durable W/KEY way in 8P modular holder
• Cut and strip wire by one operation, easy and efficient
• With round cable stripper
• For crimping modular plug as follows:
8P8C/RJ45, 8P6C, 8P4C, 8P2C;
6P6C/RJ12, 6P4C/RJ11, 6P2C
• Packing: blister card
| STOCK NO. | SIZE | QTY./CARTON |
| 38054 | 7.3“/185mm 8P/6P | 50 |
RATCHET CRIMPING PLIERS
• Applicable Wire Gauge: 0.25 to 10 mm² (AWG23-7)
• Self-Adjustable Ratchet: Featured with a star wheel for adjusting crimping pressure to deliver precise crimping and effectively prevents the ferrules from being over-crimped.
• Safety Lock & Quick Release: The handle can be locked by squeezing it when not in use and stored in a carry bag. A release trigger inside the handle pushes up when locking and quickly opening the jaws.
• ABS ergonomic handle
• Packing: blister card
| STOCK NO. | SIZE | QTY./CARTON |
| 38058 | 0.25-10mm² | 40 |
AUTO WIRE STRIPPER (INDUSTRIAL)
• 8" / 200mm •Zinc alloy head •Cr12MoV, HRC52-60° •Black finished surface •Two-component plastic handle •Stripping Gauge: 24-10AWG / 0.2-6mm² •Cutting/Crimping: 22-10AWG / 0.5-6mm² •Non insulated Terminal: 12-10AWG / 4-6mm² •Non insulated Terminal: 16-14AWG / 1.5-2.5mm² •Non insulated Terminal: 22-18AWG / 0.5-1mm² •Packing: double blister
| STOCK NO. | SIZE | QTY./CARTON |
| 38048 | 200mm, 8" | 40 |
RATCHET CRIMPING PLIERS
• Carbon steel with hardened and tempered jaws
• Continuous crimping at preset tension ensures accurate crimp
• Chemically black finished surface
• PVC grips
• Suitable for crimping insulated terminals as follows:
DIN 0.5-1.0 / 1.5-2.5 / 4-6 mm²
AWG 22-18 / 16-14 / 12-10
• Packing: blister card
| STOCK NO. | SIZE | QTY./CARTON |
| 38056 | 8.7"/220mm DIN 0.5-6mm² | 30 |
MULTI-FUNCTION STRIPPING COMBINATION PLIERS (INDUSTRIAL)
• Size: 8.5" / 215mm
• Patent Design
• Drop forged from high-quality chrome vanadium steel, overall heat treatment, induction hardened cutting edge stays sharper, longer.
• Larbor-saving design 32%
• The external side of the jaw provides a file pattern, which can easily remove sharp burrs on the surface of the workpiece.
• Toothed jaws provide a stronger clamping force.
• Asymmetrical round clamp, more powerful to clamp the surface of object.
• Sharp and hardened cutting edge suitable for common copper and iron wires cutting.
• Crimping function suitable for 0.5-1mm²，1.5-2.5mm² terminals.
• Wire stripper and crimper capacity: 18-10 AWG solid wire (18-16-14-12-10) / 1.0-2.6mm² (1.0-1.3-1.6-2.0-2.6)
• Five fully ground precision wire stripping holes made from independent high-quality manganese steel heat treatment, easy wire stripping without damaging the wire core.
• Packing: double blister
| STOCK NO. | SIZE | QTY./CARTON |
| 10294 | 215mm, 8.5" | 36 |
