TCT HOLE SAW
• 3-ply cutters reduce tip crack even with hard use
• Special Carbide tip can drill the Stainless Steel
sheet smoothly and nicely
• Long life working off the hardened steel
• Apply on portable and pillar drilling machines
• Packing: plastic box with color label
STOCK NO. | SIZE | QTY./CARTON |
75914 | 14mm | 80 |
75915 | 15mm | 80 |
75920 | 20mm | 80 |
75922 | 22mm | 80 |
75923 | 23mm | 80 |
75925 | 25mm | 80 |
75926 | 26mm | 80 |
75930 | 30mm | 60 |
75932 | 32mm | 60 |
75935 | 35mm | 60 |
75938 | 38mm | 60 |
75940 | 40mm | 60 |
75942 | 42mm | 40 |
75945 | 45mm | 40 |
75948 | 48mm | 40 |
75950 | 50mm | 40 |
75955 | 55mm | 40 |
75960 | 60mm | 40 |
75965 | 65mm | 30 |
75970 | 70mm | 30 |
75975 | 75mm | 30 |
FLAT CUTTING-OFF WHEEL (TYPE 41)
• For metal & stainless steel
STOCK NO. | SIZE | MAX.RPM | QTY./CARTON |
76130 | 105x1.0x16mm 4"x1/25"x5/8" | 15,300 | 400 |
76132 | 115x1.0x22.2 mm 4-1/2" x 1/25" x 7/8" | 13,300 | 400 |
76133 | 125x1.0x22.0 mm 5" x 1/25" x 7/8" | 12,250 | 400 |
76101 | 105x1.2x16mm 4 ″x1/21″x5/8″ | 15300 | 400 |
76102 | 115x1.2x22.2mm 4-1/2″x1/21″x7/8″ | 13300 | 400 |
76103 | 125x1.2x22.2mm 5″x1/21″x7/8″ | 12250 | 400 |
76105 | 180x1.6x22.2mm 7″x1/16″x7/8″ | 8500 | 200 |
76107 | 230x2.0x22.2 mm 9″x1/12″x7/8″ | 6650 | 100 |
76120 | 350x3.0x25.4mm 14″x1/8″x1″ | 4400 | 25 |
TCT SAW BLADE
• Suitable for wood cutting
• Packing: double blister
STOCK NO. | SIZE | REDUCTION RING | QTY./CARTON |
76410 | 110mm(4-3/8") x 40T x 20mm | 16mm | 100 |
76419 | 115mm(4-1/2") x 24T x 22.2mm | 16mm | 100 |
76420 | 115mm(4-1/2") x 40T x 22.2mm | 16mm | 100 |
76425 | 160mm x 24T x 20mm | 16mm | 50 |
76426 | 160mm x 40T x 20mm | 16mm | 50 |
76430 | 185mm(7-1/4") x 24T x 30mm | 16/20 / 22.2 /25.4mm | 50 |
76431 | 185mm(7-1/4") x 40T x 30mm | 16/20 / 22.2 /25.4mm | 50 |
76432 | 185mm(7-1/4") x 60T x 30mm | 16/20 / 22.2 /25.4mm | 50 |
76440 | 210mm(8-1/4") x 24T x 30mm | 16/20 / 22.2 /25.4mm | 50 |
76441 | 210mm(8-1/4") x 48T x 30mm | 16/20 / 22.2 /25.4mm | 50 |
76450 | 235mm(9-1/4") x 40T x 30mm | 16/20 / 22.2 /25.4mm | 25 |
76451 | 235mm(9-1/4") x 60T x 30mm | 16/20 / 22.2 /25.4mm | 25 |
76460 | 254mm(10") x 40T x 30mm | 16/20 / 22.2 /25.4mm | 25 |
76461 | 254mm(10") x 60T x 30mm | 16/20 / 22.2 /25.4mm | 25 |
76470 | 305mm(12") x 60T x 30mm | 16/20 / 22.2 /25.4mm | 10 |
76171 | 305mm(12") x 80T x 30mm | 16/20 / 22.2 /25.4mm | 10 |
76176 | 355mm x 80T x 30mm | 16/20 / 22.2 /25.4mm | 10 |
TCT SAW BLADE FOR ALUMINIUM
• Suitable for alumimium cutting
• Packed by double blister
STOCK NO. | SIZE | REDUCTION RING | QTY./CARTON |
76540 | 210mm(8-1/4") x 60T x 30mm | 16/ 20 / 22.2 / 25.4mm | 50 |
76560 | 254mm(10") x 80T x 30mm | 16/ 20 / 22.2 / 25.4mm | 25 |
76561 | 254mm(10") x 100T x 30mm | 16/ 20 / 22.2 / 25.4mm | 25 |
76570 | 305mm(12") x 100T x 30mm | 16/ 20 / 22.2 / 25.4mm | 10 |
76571 | 305mm(12") x 120T x 30mm | 16/ 20 / 22.2 / 25.4mm | 10 |
ULTRATHIN DIAMOND DISC (INDUSTRIAL)
• Ideal for brick, plaster, tile-special
• Packing: double blister
STOCK NO. | SIZE | BLADE WIDTH | MAX. RPM | QTY./CARTON |
76750 | 105x20 (16)mm 4"x25/32" | 1.4x8mm | 15,300 | 100 |
76751 | 115x22.2 (20)mm 4-1/2"x7/8" | 1.2x8mm | 13,300 | 100 |
76752 | 125x22.2 (20)mm 5"x7/8" | 1.4x8mm | 12,250 | 100 |
76753 | 180x22.2 (20)mm 7"x7/8" | 1.6x8mm | 8,500 | 40 |
76754 | 230X22.2 (20)mm 9"x7/8" | 1.8x8mm | 6,650 | 20 |
